Class Limit Power Mode
To configure class limit power mode:
1.
Click Configuration > Port Management > PoE > Class Limit Power Mode.
•
PoE Status—Enable or disable PoE on the port.
•
Power Priority Level—Port priority is low, high, or critical, for use when the power
supply is low. For example, if the power supply is running at 99% usage and port 1
is prioritized as high, but port 3 is prioritized as low, port 1 receives power and port
3 might be denied power.
•
Class—Class configured on this port. The classes are shown in the following:
Class
Maximum Power Delivered by Device Port
0 15.4 watt
1 4.0 watt
2 7.0 watt
3 15.4 watt
4 30.0 watt
•
Max Power Allocation (mW)—Maximum amount of power permitted on this port.
The switch hardware may actually supply 5-10% more power than Max Power
Allocation to accommodate the power loss over the wire.
•
Power Consumption (mW)—Amount of power assigned to the powered device
connected to the selected interface.
•
Operational Status—Whether the Class Limit mode is enabled or disabled on the
port.
