How To Use QuickSwitch Plus
Product Selection
Linx 7900
When you select a new product, the Print Monitor page displays the title ‘Current
Product’ with the product selection name below, instead of the normal title
(‘Current Message’). This is to avoid confusion, because a product name does not
have to be the same as that of the message associated with it and a single message
can be used for multiple products. As shown in Figure 10, the current product
selection is called ‘SMALL BEANS’.
Figure 10. Print Monitor page: Current Product
If a message is selected, the Print Monitor page reverts to display the title ‘Current
Message’, with the message name below.
