ATTACK
™
DIGITAL FIRE TRAINING SYSTEM
12
WWW.LIONPROTECTS.COM
6. Next, slide the rear support bar back and insert the legs over the two bolts on the rear
of the base plate.
7. Close the two plugs at the bottom of the water tank.
8. Fill the tank with water until it is full.
9. Connect the power cord to the back of ATTACK
™
panel. Do not use power cords that
were not provided by LION. Align the triangle features on the connector and the plug.
The power cord will always run towards the bottom of the panel when connected.
Push the connector into the plug. There is no need to twist the collar on the plug.
You will hear a click when the connector latches onto the plug correctly.
10. Insert the bottom of the panel into the bottom brackets on the weighted base.
STEP 9 (B) STEP 9 (C)
STEP 6
STEP 9 (A)
STEP 7
STEP 8
