Lippert Components OneControl ConnectAnywhere User Manual

Rev: 03.25.19 Page 4
CCD-0001447
Callout Part # Description Qty
A 714393 LCI ConnectAnywhere Kit - 10-foot 1
B 711151 LCI Cloud Gateway 1
C 714787 Cellular Gateway 1
D 722251 Wi-Fi Antenna, 2.4 GHz (part of "C") 2
E 722256 NANO SIM Card Adapter (part of "C") 1
F 766122 2.1mm DC Plug-to-2.1mm DC Plug Power Harness (part of "C") 1
G 767657 Ethernet Patch Cable (part of "C") 1
H 716727 Router Ethernet Cable 1
I 715645 SMA M/M Cellular Coaxial Cable—10 ft (Non-prepped) 2
J 329080 CAN bus Power Cable 2
K 722255 Antenna, 4G External, Pigtail 1
Preparation
System Components
Fig. 1
A
B
D
C
E
G
F
J
H
I
K
NOTE: Part numbers are shown for identification purposes only. Not all parts are available for individual
sale. All parts with a link to the Lippert Store can be purchased.
