Lippert Power Bimini Master - Table of Contents

Rev: 08.30.22 Page 2 CCD-0006500
TABLE OF CONTENTS
Introduction 3
Safety 4
Power Bimini Featuresif so equipped 5
Complete Quick-Connect Bimini Systemif so equipped 10
Bimini Top Positions 11
Fully Closed (Down)—Towing Position 11
Radar—For Water Use Only 12
Fully Opened (Up)—For Water Use Only 12
Operation 13
Helm-mounted Switchif so equipped 14
Key-Fob (Remote Control)if so equipped 18
Programming Additional Key-Fobs (Remotes)Optional 20
Touch Controller or Appif so equipped 21
High Speed Mesh Topif so equipped 36
Front Shade Extensionif so equipped 37
Courtesy Lightif so equipped 39
Speakersif so equipped 39
Adjustable Front Support Strapsif so equipped 40
Front Support Arms—if so equipped 40
Troubleshooting 43
Manual Override 46
Maintenance 49
Fabric Care 49
Front Support Arms 49
Trailering (Towing) 49
Storage or Storm Position 49
Winter Storage 49
Wiring Diagrams 50
Helm Switch to Actuators 50
Helm Switch and Key-Fob 51
Helm Switch to Actuators and Speakers 52
QC Controller to Actuators 53
QC Controller to Actuators and Speakers 54
Notes 55
