Rev: 08.30.22 Page 43 CCD-0006500
Troubleshooting
What Is Happening? Why? What Should Be Done?
Helm switch does not
respond.
Bad electrical
connection.
Check for loose or unconnected wires.
Connect wires.
Bad helm switch. Contact switch provider.
Bimini top will not open.
Low power. Make sure battery is fully charged.
No power.
Check actuator and helm switch electrical
connections. Reconnect loose or disconnected
connections. Refer to figure 8 and Wiring Diagram.
Inspect electrical connections for nicks and cuts.
Repair or replace as necessary. Refer to figure 8
and Wiring Diagram.
Bimini top will not close.
Low power. Make sure battery is fully charged.
No power.
Check actuator and helm switch electrical
connections. Reconnect loose or disconnected
connections. Refer to figure 8 and Wiring Diagram.
Inspect electrical connections for nicks and cuts.
Repair or replace as necessary. Refer to figure 8
and Wiring Diagram.
Damaged actuator. Perform manual override.
Foreign material
blocking gear handle.
Remove foreign material from gear handle. Inspect
gear handle and actuator for damage. Perform
manual override if necessary.
Bimini top does not fully
open or close.
Low power. Make sure battery is fully charged.
No power.
Check actuator and helm switch electrical
connections. Reconnect loose or disconnected
connections. Refer to figure 8 and Wiring Diagram.
Inspect electrical connections for nicks and cuts.
Repair or replace as necessary. Refer to figure 8
and Wiring Diagram.
Damaged actuator. Perform manual override. Contact Lippert.
Foreign material
blocking gear handle.
Remove foreign material from gear handle.
Inspect gear handle and actuator for damage.
Perform manual override if necessary.
Bimini top does not
respond to key-fob.
Weak signal. Move key-fob closer to RF Receiver.
No power.
Check power connections to RF Receiver.
Reconnect power if necessary. Refer to figure 8
and Wiring Diagram.
Use helm switch. If top responds to helm switch,
replace key-fob battery.
Key-fob transmit LED
does not light up.
Weak signal. Move key-fob closer to RF Receiver.
No power.
Check power connections to RF Receiver.
Reconnect power if necessary. Refer to figure 8
and Wiring Diagram.
Replace key-fob battery.
To Next Page
