Lippert Power Bimini Master - Power Bimini Features-If so Equipped

Rev: 08.30.22 Page 5 CCD-0006500
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury
and/or product or property damage if not safely adhered to and within the parameters set forth
in this manual.
Always wear eye protection when performing service, maintenance or installation procedures.
Other safety equipment to consider would be hearing protection, gloves and possibly a full face
shield, depending on the nature of the task.
All electrical wiring harnesses shall be loomed and secured to prevent possible damage and
installed in accordance with the latest ABYC (American Boat and Yacht Council) electrical standards,
E11 and S31
Do NOT exceed 15 mph when front shade extension is deployed. Exceeding maximum speed
limit with front shade extension deployed can cause damage to the extension and void product
warranty.
Moving parts can pinch, cut or crush. Keep clear and use caution.
Power Bimini Featuresif so equipped
The following power bimini feature illustrations identify the location of the system's key features, if
soequipped.
NOTE: The fabric top is not shown in some images for clarity.
NOTE: The fence railing is shown for illustrative and orientation purposes only. Boat fencing and railings
are NOT included in the Power Bimini system.
Securing straps are provided to prevent undue billowing of the bimini top and for the attachment of
accessories. There are three different types of straps:
• Corner Straps – two at each corner of the front leading edge. These are used to prevent the top from
moving side-to-side and to secure it when prepping the top for storage in the boot.
• Front Straps – two front adjustable straps are connected from the front frame to the pontoon rail.
NOTE: The bimini is rated for 45mph with the front straps in-place and only 25mph without the front
straps secured.
• Changing Room Attachment Straps – four loops under the canopy on either side of the middle frame (eight
loops total) for attaching a changing room.
NOTE: Make sure the corner securing straps are in place when installing the boot or operating the
biminitop.
The front shade extension connects to the open zipper end of the bimini's storage pocket.
NOTE: When the bimini front shade extension is open the maximum speed rating is 15 mph.
NOTE: Front support straps are NOT used when the front shade extension is in use. Disconnect front
support straps and stow them in the bimini top's front zippered storage pocket before deploying
the front shade extension. If so desired, reconnect the front support straps after the front shade
extension has been disconnected andstowed.
