Lippert Power Bimini Master - Page 48

Rev: 08.30.22 Page 48 CCD-0006500
7. Lift the front frame off of the gear handles (Fig. 54).
8. Place the front frame on top of the collapsed rear frame and fabric.
9. Zip the bimini top's front pocket over the loose front frame to help hold the frame in-place.
10. Install the protective boot over the collapsed rear frame, fabric and front frame (Fig. 55) to secure the
bimini system in-place.
11. Secure the remainder of the frame struts with zip ties, hook-and-loop strips or with some other type
ofcordage.
Fig. 54
Fig. 55
Front Frame
Gear Handle
Boot
Front Frame
Gear Handle
Gear Handle
