Rev: 10.13.21 Page 16 CCD-0004221
Operation
When Sensors are under pressure, data is transmitted to the repeater when tires are:
• moving/rotating, every one minute;
• not moving/not rotating, every 15 minutes.
1. Tap a tire location (Fig. 43) to launch its properties window (Figs. 44 and 45). Within the selected tire’s
properties window, various tire and sensor specifications can be observed and altered.
A. Pressure — posts the currently-sensed pressure of the selected tire.
B. Temperature — posts the currently-sensed temperature of the selected tire.
C. Battery Level — posts the current battery voltage of the sensor’s battery.
Fig. 43 Fig. 44
Fig. 45
Fig. 46
Tires that have high or low air pressure can cause unforeseen detrimental eects on tires and
the unit, including undesirable tread wear. Tires should always be pressurized to within the
manufacturer's recommendations.
NOTE: The individual tire thresholds listed below can only be accessed by entering the SETTINGS menu
while in the individual tire menu.
D. Minimum/Maximum Pressure — posts the currently-programmed minimum and maximum
pressure limit for the selectedtire.
E. Maximum Temperature — posts the currently-programmed maximum temperature limit for the
selected tire.
F. Maximum Temp Change — posts the currently-programmed maximum +/- temperature change
limit for the selected tire.
A
