Rev: 10.13.21 Page 17 CCD-0004221
2. When a fault is active, the display will beep and the text box that displays the temperature and
pressure for the tire experiencing the fault will turn red (Fig. 46).
NOTE: The text for the spare tire with a fault will not turn red — only the spare tire icon will turn red (Fig. 46A).
Tire Limits Example
When a specific tire information button is tapped, the tire's programmable settings become available. Find
the desired setting, select it, then tap the “back” arrow (<) located above the tire’s setting name.
The following example illustrates the interaction between the various tire settings and how the resulting
information is relayed by the monitoring system for display.
1. Select a tire by tapping its information button to launch its settings window.
A. In this example, the reported current TIRE PRESSURE is listed as 16 psi (11 kPa).
NOTE: Stem Sensor Pressure Reading Tolerance: +/-1.5 psi (+/-10.3 kPa).
For example—because of differences in accuracy and conversion between a Stem Sensor and a
tire gauge—actual tire pressure at 38 psi (262 kPa) may be reported by the Stem Sensor as 36 psi
(248.2kPa) while the tire gauge may report 40 psi (275.8 kPa).
B. Compare the tire’s low/high pressure range against the reported tire pressure (16 psi). Always
make sure tire pressures are within recommendedlimits.
2. If the Maximum Pressure requires adjusting, tap the next arrow to launch its settings window (Fig. 45).
Scroll through the window until the current setting is found, then scroll to a new limit and select it.
3. If the Minimum Pressure requires adjusting, tap the next arrow to launch its settings window (Fig. 45).
Scroll through the window until the current setting is found, then scroll to a desired limit and select it.
NOTE: The Maximum Temperature and the Maximum Temp Change (Fig.45) can also be adjusted in
similar fashion.
NOTE: Stem Sensor Temperature Reading Tolerance: +/-5.4 °F (+/-3 °C).
For example, if a Stem Sensor reports tire temperature at 85 °F (29 °C), actual tire temperature may
be 90.4–79.6 °F (32–26 °C).
NOTE: Stem Sensor Working Range: 185 to -4 °F (85 to -20 °C).
Changing Units of Measure
To change the units of measure—to/from Imperial/Metric—go to the SETTINGS screen:
1. Tap the Display button's next arrow (Fig. 41A).
2. From the DISPLAY screen (Fig.42), select the desired unit of measure; US or Metric.
NOTE: Displayed units of measure will change to match the newly selected units.
3. Tap the back arrow above the screen title to return to the SETTINGS screen.
