Lippert Tire Linc - Sensor Pairing Sequence

Rev: 10.13.21 Page 7 CCD-0004221
Sensor Pairing Sequence
The pairing sequence for tires begins with the left front tire first (Fig. 11-1), continuing from front to rear and
then beginning again at the right front (Fig. 11-5) and continuing to the rear tires. The spare tire (Fig. 11-9)
islast.
With dual wheels on a vehicle, the outside tires on either side (Fig. 11-2, 6) are paired first before the inside
tires (Fig. 11-3, 7).
Figure 11 provides an example of the pairing sequence for tires on any vehicle.
Fig. 11
Rear
1
2
3
4
5
6
7
8
9
Spare
Front
