Rev: 10.13.21 Page 19 CCD-0004221
Fig. 48
Reset
Pair Mode Button
Fig. 49
No Power
If system is not working, check the in-line fuse to the dock to ensure the repeater dock has power.
Reset Repeater
1. Tap and hold the Pair Mode button on the repeater (Fig. 48) for approximately 10 seconds.
2. Continue holding the button until there is one long red blink followed by four short red blinks.
3. Release button.
Reset LCD Handheld Display
1. Bend the end of a paper clip or use a similar tool that will fit into the reset hole in the LCD display (Fig. 49).
2. Insert the tool then tap and hold for two seconds to reset the display.
To Next Page
