Rev: 10.13.21 Page 8 CCD-0004221
Learn All Sensors
A screen will appear on the display for five seconds (Fig. 3) before automatically transitioning to the
notifications received before sensor learning takes place.
1. After entering the Learn All Sensors mode, hold the LCD display close to the sidewall in the area
opposite the valve stem of the tire to be paired (Fig. 12).
2. Tap and hold the sync button on the LCD display (Fig. 4) to pair the sensor until the display beeps and
the red flashing circle turns green.
3. The display will feature a red dot (Fig. 13A) representing the tire that is being paired, which will then
turn green (Fig. 14A) when it is successfully paired (Figs. 13 and 14).
4. When pairing has been completed, the display will ask if another vehicle is to be added to the
system (Fig. 15). If tapping YES, pair the additional sensors in the proper sequence. If not, continue to
Configure All Thresholds.
NOTE: There are limits of three vehicles and 20 tires.
Fig. 12
Fig. 13
Fig. 14
Fig. 15
A
A
