ISO 9001 CERTIFIED www.liteputer.com.tw
Lite-Puter
CX-12 [EUM-E]
2
Chapter 1. CX-12II Feature & Function
1-1 Feature
Digital signal output
96 control channel, and able to control up to CH97 – CH512 by patch
4 set of PATCH editing function
96 set of scenes pre-set
( 24 set of scenes able to save on every single page function )
24 set of chase preset
Up to 64 scene step on each chase setting
2 set of individual control stick for scenes change (CROSS FADE)
Audio control available
output external memory card saving / loading ( option )
1-2 Specification
Power supply AC 90-240V, 45-63Hz
Digital control signal input / output DMX512 / 1990
Digital control channel 512channel by PATCH able to control
CH 97 – CH 512
Digital control connector XLR 5-pin, XLR 3-pin, RJ11
Audio input
Internal microphone MAX 120dB， output
max. value :AC 100mV
Gooseneck connector stand XLR 3 -pin, DC +12V 250mA
Memory card 64k*2
Dimension 19” 8U standard rack
482(w) x 352(h)x125(d)mm
Weight 5 Kg
Warning！
1. Recharge the battery at least 24 hours on before start running. ( power
switch turn to ON locate on rear panel )
2. After first use, the saving data may lost if without battery recharge in 7
days!
To Next Page
