LiteOn EVO 8000 Series User Manual

142
7.4 MODBUS Data List
The MODBUS data list is as follows. The types of data include command data, monitoring data, and
broadcast transmission data.
 Instruction DATA (can be read and written)
Site
Definition
2400H
Retain
2401H
Operational order
BIT 0
Stop/Run (0: Stop, 1: Run)
BIT 1
Forward/reverse (0: forward, 1: reverse)
BIT 2
External fault EF0 0: No function 1: External
fault
BIT 3
Fault reset 0: No function 1: Fault reset
BIT 4
Retain
BIT 5
Retain
BIT 6
Retain
BIT 7
Retain
BIT 8
Multi-function terminal 1 (0:Off,1: ON)
BIT 9
Multi-function terminal 2 (0:Off,1: ON)
BIT 10
Multi-function terminal 3 (0:Off 1: ON)
BIT 11
Multi-function terminal 4 (0:Off 1: ON)
BIT 12
Multi-function terminal 5 (0:Off 1: ON)
BIT 13
Multi-function terminal 6 (0:Off 1: ON)
BIT 14
Multi-function terminal 7 (0:Off 1: ON)
BIT 15
Multi-function terminal 8 (0:Off 1: ON)
2402H
Frequency command (unit: 0.01Hz)
2403H
Torque command (-16384 ~ 16384
corresponds to -200% ~ 200% motor rated
torque)
 Monitor DATA (read only)
Site
Definition
2420H
Retain
2421H
Operational state
BIT 0
1: In operation
