LiteOn EVO 8000 Series User Manual

143
BIT 1
1: Reverse running
BIT 2
1: Zero speed
BIT 3
1: malfunction
BIT 4
1: caution
BIT 5
1: Consistent frequency
BIT 6
1: The inverter is ready to run.
BIT 7
1: Frequency provided by communication
BIT 8
1: Operation provided by communication
BIT 9
1: Torque mode
BIT 10
1: Zero servo mode
BIT 11~15
Retain
2422H
Frequency command (Unit 0.01Hz)
2423H
Output frequency (Unit 0.01Hz)
2424H
Output current (Unit 0.01A)
2425H
output voltage (Unit 0.1V)
2426H
DC voltage (Unit 0.1V)
2427H
Warning description
2428H
Fault description
2429H
Multi-function input and output status
BIT 0
1: Multi-function terminal 1 ON
BIT 1
1: Multi-function terminal 2 ON
BIT 2
1: Multi-function terminal 3 ON
BIT 3
1: Multi-function terminal 4 ON
BIT 4
1: Multi-function terminal 5 ON
BIT 5
1: Multi-function terminal 6 ON
BIT 6
1: Multi-function terminal 7 ON
BIT 7
1: Multi-function terminal 8 ON
BIT 8~10
Retain
BIT 12
1: Relay1 ON
BIT 13
1: Relay2 ON
BIT 14
1: PH1 ON
BIT 15
Retain
242A
H
AI1 Input (0 correspond 0V or 0mA, 1000 correspond 10V or 20mA)
242B
H
AI2 Input (0 correspond 0V or 4mA, 1000 correspond 10V or 20mA)
242C
Retain
