LiteOn EVO 8000 Series User Manual

16
Operating Environment
Area of Use
Indoor without corrosive gas/liquid or flammable gas/liquid/oil
mist/dust
Ambient
Temperature
-10℃ to +50℃, -10℃ to +40℃ (NEMA1), below 95% RH without
froze or condensation
Storage
Temperature
-20℃ to +60℃
Altitude
Up to 1000 meters
Shock
10 to 20 Hz (9.8 m/s2) , 20 to 55 Hz (5.9 m/s2)
Enclosure
IP20, NEMA1 (with optional NEMA kit)
Number of
I/O
Analog Input (AI)
2 points (AI1: 0 to 10V, -10V to 10V (12 bits); AI2: 0/4 to 20mA, 0V to
10V, 0 to 5V)
Digital Input (DI)
8 points
Analog Output (AO)
2 points FM: 0 to 10V, -10V to 10V (10 bits), AM: 0 or 4 to 20mA (10
bits), 0 to 10V(11 bits)
Digital Output (DO)
2 points
Relay Output (RO)
2 points
Pulse Input (PI)
1 point
Pulse Output (PO)
1 point
Communications
Modbus (RS-485 port), USB port
Communication Option
Card
EtherCAT*2
Short circuit current
The current is below 5000A and the relative maximum voltage is 480 V
ac.
Reference specification
UL 508C, CSA C22.2 no .274, IEC 61800-5-1, IEC 61800-3
*1. Results tested in labs
*2. Under development
