138
Overtorque detection is active when the Run command is active. The drive continues to run
after an ot1 (Overtorque Detection 1) alarm is triggered.
3 : Overtorque Fault at Speed Agree
Overtorque detection is active only when the output frequency is the same as the frequency
command. No detection during acceleration or deceleration. The drive stops operation after
an ot1 (Overtorque Detection 1) fault is triggered.
4 : Overtorque Fault at Run
Overtorque detection is active when the Run command is active. The drive stops operation
after an ot1 (Overtorque Detection 1) fault is triggered.
5 : Undertorque Alarm at Speed Agree
Undertorque detection is active only when the output frequency is the same as the frequency
command. No detection during acceleration or deceleration. The drive continues to run after
an Ut1 (Undertorque Detection 1) alarm is triggered.
6 : Undertorque Alarm at Run
Undertorque detection is active when the Run command is active. The drive continues to run
after an Ut1 (Undertorque Detection 1) alarm is triggered.
7 : Undertorque Fault at Speed Agree
Undertorque detection is active only when the output frequency is the same as the frequency
command. No detection during acceleration or deceleration. The drive stops operation after
an Ut1 (Undertorque Detection 1) fault is triggered.
8 : Undertorque Fault at Run
Undertorque detection is active when the Run command is active. The drive stops operation
after an Ut1 (Overtorque Detection 1) fault is triggered.
P6-01 Overtorque/ Undertorque Detection Level 1
Sets the level for overtorque/undertorque detection
Overtorque/ undertorque detection is set as a percentage of the drive rated output current in
Open-Loop V/F Control, Closed-Loop V/F Control, and PM Open-Loop Vector Control control
methods. Overtorque/ undertorque detection is set as a percentage of the motor rated torque
in Open-Loop Vector Control, Closed-Loop Vector Control, and PM Closed-Loop Vector
Control control methods.
