 +V is the input terminal for auxiliary power.
4.3.1 Control Circuit Terminals
4.3.1.1 Input Terminals
Table 4.3.1.1 Control Circuit Input Terminal
Terminal Type
Terminal
Code
Terminal Name
Terminal Description
Multi-Function
Digital Inputs
S1
Digital input terminal 1 (forward/stop)
Photocoupler, 24 V, 8 mA.
Use NPN/PNP switch to select
multi-function digital input
type. The default is NPN mode.
S2
Digital input terminal 2 (reverse/stop)
S3
Digital input terminal 3 (external fault
1)
S4
Digital input terminal 4 (fault reset)
S5
Digital input terminal 5 (Jog)
S6
Digital input terminal 6 (Baseblock)
SC
Digital input common terminal for NPN/PNP mode switch. Select the mode
correctly when connecting.
Multi-Function
Analog Inputs
+V
Auxiliary power terminal +10V
Analog input power+10V
A1
Analog input terminal 1
(main frequency command)
Voltage input:
0 to 5V or 0 to 10V
Current input:
0 or 4 to 20mA
PE
Ground terminal
The ground terminal for control
signals to avoid interference.
Use shielded cables only.
AC
Common terminal for analog signals
4.3.1.2 Output Terminals
Table 4.3.1.2 Control Circuit Output Terminals
Terminal Type
Terminal
Code
Terminal Name
Terminal Description
Multi-Function
Relay Output
R1A
Relay 1 normal open
Relay output
DC 30 V, 1 A
AC 250 V, 5 A
R1B
Relay 1 normal closed
R1C
Relay 1 common
Multi-Function
Analog Output
FM
Programmable analog output
terminal (output frequency)
Voltage Output
0 to 10V
AC
Analog common terminal
<1> Do not assign frequent switching functions such as ON/OFF to terminals R, which may
