LiteOn EVO600043S1D5E20F User Manual

177
Chapter 11│Communications
11.1 Modbus Communication Specifications
Item
Specifications
Interface
RS-485
Communications Cycle
Asynchronous
Communication Parameters
Communication speeds
Data length
Select even, odd or none
Stop bit
Protocol
Modbus
Max number of Slaves
31 AC drives
11.2 Connecting to Controller/PLC/HMI
11.2.1 Communication Cable Connection
1. Connect the communications cable to the drive and the controller/PLC/HMI when the power
is cut off. Use the drive terminal RJ45 for Modbus communication.
Note: To prevent the interference, separate the communications cables from the main circuit
cables, power cable and other wiring. Always use shielded cables for the communications
cables, and shielded clamps.
2. Turn the power on.
3. Set the parameters needed for the communication(E6 - 00 to E6 - 12) using the keypad.
4. Shut the power off and wait until the display goes out.
5. Turn the power on.
6. The communication between the drive and the controller/PLC/HMI is now ready.
RS-48
5
Modbus RS-485
Pin 1, 2, 7, 8: Retain
Pin 3, 6:SGND
Pin 4:SG-
Pin 5:SG+
8
1
RS-485
8
1
Pin 1:15v
Pin 2:5v
Pin 3,6:SGND
Pin 4:SG-
Pin 5:SG+
Pin 7, 8:Reserved
