Chapter 3│Drive Installation
3.1 Installation Environment
To ensure the optimum drive performance, install the AC drive in a proper environment
specified below.
Environment
Conditions
Area of Use
Indoors
Ambient
Temperature
 -10°C to +50°C (IP20 enclosure)
 Do not install the drive in environments with wide temperature fluctuations
so as to ensure the drive reliability.
 When the drive is installed in an enclosure cabinet, make sure the cooling
works properly to keep the temperature within the specified levels.
 Do not allow the drive to freeze.
 When drives are installed side-by-side in a cabinet, follow the instruction
illustrated in Figure 3.2 to ensure the air flow.
Humidity
 Under 90% RH
 Free of condensation
Storage
Temperature
-20°C to +60°C
Surrounding
Area
 Free from water, oil, metal shavings or other foreign materials.
 Free from flammable materials (e.g., wood)
 Free from harmful gases and liquids
 Free from direct sunlight
 Free from oil mist, corrosive gas, flammable gas or dust.
 Free from radioactive material
 Green Class 2 or above
Altitude
Up to 1000 m without derating. Up to 2000 meters with 1% rated current
derated for every 100 m counted from 1000 m.
Vibration
 10 to 20 Hz at 9.8 m/s2
 20 to 55 Hz at 5.9 m/s2
Enclosure
IP20
