6.2 Group b, Application
b1: Operation Mode Selection
 b1- 00 Frequency Command Selection 1
Selects the frequency command source for the REMOTE mode.
Note:
 When the run command is input with 0 Hz frequency command or below the minimum frequency, the RUN
LED will blink.

No.
Name
Setting Range
Default
b1-00
Frequency Command Selection 1
0 to 3
0
0 : Keypad
Allows two ways to input the frequency command.
 Switching between the multi-step speed command in parameters L1-□□ (by digital input
terminal).
 Entering the frequency command on the keypad.
1 : Control Circuit Terminal (Analog Input)
Allows a voltage or current input as analog frequency command from terminal A1.
□ Voltage Input
Allows a voltage signal input via terminals A1. Refer to Table 6.4 for parameter settings.
Table 6.4 Frequency Command Using Voltage Signals
Terminal
Signal
Level
Parameter Settings
Notes
Signal Level
Selection
Function Selection
Gain
Bias
A1
0 to 10 V
E3-00 = 2
E3-01 = 0
(Main Frequency Command)
E3-02
E3-03
Ensure DIP switch A1 is
placed to V (voltage)
-10 to 10 V
E3-00 = 3
