LiteOn EVO600043S1D5E20F User Manual

149
Parameter
Name
Description
Unit
U1-11
Drive Operation
Status
Displays the status of the drive operation.
U1-11=11111111
The following indicate each digit from right to left.
1:During Run
1:During Zero Speed Holding
1:During Reverse
1:During Fault Reset Signal Input
1:During Speed Agree
1:Drive Ready
1:During Alarm Detection
1:During Fault Detection
-
U1-12
Terminal A1 Input
Voltage
Displays the terminal A1 input voltage.
0.1%
U1-16
Software Version
Displays the software version.
-
U2: Fault Information
U2-00
Current Fault
Displays the current fault.
-
U2-01
1
st
Most Recent Fault
Displays the first most recent fault.
-
U2-02
2
nd
Most Recent
Fault
Displays the second most recent fault.
-
U2-03
3
rd
Most Recent Fault
Displays the third most recent fault.
-
U2-04
4
th
Most Recent Fault
Displays the fourth most recent fault.
-
U2-05
Frequency
Command at 1
st
Most Recent Fault
Displays the frequency command at the first most recent
fault.
-
U2-06
Output Frequency at
1
st
Most Recent Fault
Displays the output frequency at the first most recent fault.
-
U2-07
Output Current at 1
st
Most Recent Fault
Displays the output current at the first most recent fault.
0.01A
U2-08
Motor Speed at 1
st
Most Recent Fault
Displays the motor speed at the first most recent fault.
0.1rpm
U2-09
Output Voltage
command at 1
st
Most Recent Fault
Displays the output voltage command at the first most recent
fault.
0.1V
U2-10
Main Circuit DC
Voltage at 1
st
Most
Recent Fault
Displays the main circuit DC voltage at the first most recent
fault.
0.1V
U2-13
Input Terminal Status
at 1
st
Most Recent
Fault
Displays the input terminal status at the first most recent
fault. (Same status display as U1-09)
-
U2-14
Output Terminal
Status at 1
st
Most
Displays the output terminal status at the first most recent
fault. (Same status display as U1-10)
-
