LiteOn EVO600043S1D5E20F User Manual

161
Keypad
Display
Fault Name
Cause
Possible Solution
interference causes drive
malfunction
11. Run command was
applied while motor was
coasting
12. Motor code is set
incorrectly
13. The motor does not
match the drive control
method
14. The motor cable is too
long
10.Check the amount of torque
compensation
11. >Find out possible solutions
to suppress the electrical signal
interference.
>Input Speed Search command
via multi-function input terminal
12. Enable Speed Search via
multi-function input terminal
14. Check the control method
(A1-02)
15. Use a larger drive
SC
IGBT Fault or Output
Short Circuit
1. Motor has been damaged
due to the motor insulation
weakened or overheat
2. The cable is damaged
3. Hardware fault
4. The drive is damaged
1. Replace the motor or check
the motor insulation resistance
2. Repair any short circuits and
check the motor power cable
EF0
Retain
EF1 to
EF6
External Fault
（Input Terminal S1
to S6）
1. An external device tripped
an alarm
2. Incorrect wiring
3. Multi-function input wiring
is not correct
1. Remove the cause of the
external fault then reset the
multi-function input.
2. Confirm if the signal lines is
properly connected to the
terminals assigned for external
fault detection (E1-口口= 23 to
38)
3. Confirm if E1-口口=23 to 38 is
set to the unused terminals.
oH
Heatsink Overheat
Heatsink
temperature over 95
°C
1. Ambient temperature is
too high
2. Internal cooling fan
stopped operating
3. Bad air flow due to
insufficient room.
1. Check the temperature
surrounding the drive
a. Improve the air flow inside the
enclosure panel
b. Install an air conditioner or fan
to cool the environment
c. Remove any possible source of
heat
2. Measure the output current
a. Reduce the load
b. Lower setting in C6-00
