b5-24 Sets the display value when run at the maximum frequency.
b5-25 Sets the number of decimal places to display..
No.
Name
Setting Range
Default
b5-24
PID Target Display Value
1 to 60000
0
b5-25
PID Target Display Digits
0 to 3
Determined by b5-19
0 ∶ No Decimal Places
1 ∶ 1 Decimal Place
2 ∶ 2 Decimal Places
3 ∶ 3 Decimal Places
 b5- 26 Frequency Reference Monitor Content During PID
Sets the content of the frequency reference monitor display (U4-08) when PID control is
active.
No.
Name
Setting Range
Default
b5-26
Frequency Reference Monitor
Content During PID
0 、 1
0
0: Frequency Reference after PID
Monitor U4-08 displays the frequency reference increased or reduced for the PID output.
1: Frequency Reference
Monitor U4-08 displays the frequency reference value.
 b5- 27 PID Output Reverse Selection 2
Determines whether a negative PID output reverses the direction of drive operation. When the
PID function is used to trim the frequency reference (b5-00 = 3 or 4), this parameter has no
effect and the PID output will not be limited。
No.
Name
Setting Range
Default
b5-27
PID Output Reverse Selection 2
0 、 1
1
Note : Set in b1-03 for the stop reverse, set b5-27 is ignored
0: Reverse Disabled
Negative PID output will be limited to 0 and the drive output will be stopped.
1: Reverse Enabled
Negative PID output will cause the drive to run in the opposite direction.
■ PID Fine-Tuning
Follow the following instructions when the PID control parameters are set.
