 L1-00 to L1-15 Frequency Command 1 to 16 and L1-16 Jog Frequency Command
The drive allows the user to switch between up to 16 frequency commands and 1 Jog
frequency command. The drive uses the selected acceleration and deceleration times when
switching between each frequency command.
The Job frequency command overrides frequency command 1 to 16.
No.
Name
Setting Range
Default
L1-00 to L1-15
Frequency Command
1 to 16
0.00Hz to <1>
<2> <3>
L1-00 5.00Hz
L1-01 8.00Hz
L1-02 10.00Hz
L1-03 12.00Hz
L1-04 15.00Hz
L1-05 20.00Hz
L1-06 25.00Hz
L1-07 30.00H7
L1-08 35.00Hz
L1-09 40.00Hz
L1-10 42.00Hz
L1-11 45.00Hz
L1-12 50.00Hz
L1-13 50.00Hz
L1-14 50.00Hz
L1-15 50.00Hz
L1-16
Jog Frequency
Command
0.00Hz to <1>
<2> <3>
6.00 Hz <2>
<1> The upper limit is determined by d1-02 (Maximum Output Frequency) and L2-00 (Frequency Command Upper
Limit).
<2> If L2-00 (Frequency Upper Limit) is adjusted, the excessive frequency in L1-00 to L1-15 will be automatically
set to the upper limit determined in L2-00.
□ Setting Multi-Step Speed
To assign a multi-step speed command to a multi-function input, set E1-□□= 5, 6, 7, 8
(Multi-Step Speed 1, 2, 3, 4). To assign the Jog frequency command to a multi-function input,
set E1-□□ =9.
Table 6.12 Multi-Step Speed Command and Multi-Function Terminal Combinations
Frequency Command
Multi-Step
Speed
Command 1
E1-□□=5
Multi-Step
Speed
Command 2
E1-□□=6
Multi-Step
Speed
Command 3
E1-□□=7
Multi-Step
Speed
Command 4
E1-□□=8
Multi-Step
Speed
Command 5
E1-□□=9
