<1> The braking transistor operation level.
■ V/F Pattern Setting( d1-01)
The set V/F pattern determines the output voltage according to the frequency command.
There are 15 different preset V/F patterns (setting 0 to E: only the maximum voltage and base
voltage can be changed) and user-defined V/F patterns d1-02 to d1-11 (setting F).
d1- 01 V/F Pattern Selection
Selects 1 V/F pattern from the preset 15 ones or sets the user-defined V/F pattern.
<1> This will not be reset by A1-03 (Reset).
<2> In Vector Control, d1-01 =F.
□ Preset V/F Pattern Selection (Setting Value 0 to E)
The preset V/F patterns are listed in Table 6.13. Select the appropriate V/F pattern and set to
this parameter. d1-02 to d1-11 cannot be edited.
Note:
1. An improper V/F could cause motor undertorque or increased current because of overexcitation.
2. d1-01 will not be reset by A1-03 (Reset).
Table 6.13 V/F Pattern Selection
For general purpose applications such as
conveyors. The torque remains constant
regardless of the speed.
For applications such as fans, pumps and
other derated loads.
50 Hz, mid starting torque
· Long wiring between the drive and motor
(more than 150 m)
50 Hz, high starting torque
