LiteOn EVO600043S2D2E20F User Manual

15
Enclosure
IP20
I/O
Analog Input (AI)
1 point (AI: 0 to 5V, 0 to 10V (12 bits), 0 or 4 to 20mA(11 bits))
Digital Input (DI)
6 points
Analog Output (AO)
1 point (FM: 0 to 10V (10bits))
Digital Output (DO)
0
Relay Ｏutput (RO)
1 point
Communications
Modbus (RS-485 port)
Option Card
Profibus-DP, CANopen, DeviceNet
Short-Circuit Current
Under 5000A. Relatively maximum voltage is 480 V circuit.
Certificate
UL 508C, CSA C22.2 no .14, IEC 61800-5-1, IEC 61800-3
*1. Results tested in labs
2.7 Product Dimensions
Frame Size 1: EVO600021S0D2E20F, EVO600021S0D4E20F, EVO600021SD75E20F,
EVO600043S0D4E20F, EVO600043SD75E20F, EVO600043S1D5E20F
Frame Size 2: EVO600021S1D5E20F, EVO600021S2D2E20F, EVO600043S2D2E20F,
EVO600043S3D7E20F
Frame Size 1 Frame Size 2
Unit: mm/inch
