61
Sets the upper limit of output from PID control as a percentage of the maximum frequency.
No.
Name
Setting Range
Default
b5-05
PID Output Limit
0.0 to 100.0%
100.0%
 b5- 06 PID Bias Voltage Adjustment
Sets the PID bias voltage adjustment as a percentage of the maximum frequency to add to the
PID control output.
No.
Name
Setting Range
Default
b5-06
PID Bias Voltage Adjustment
-100.0 to 100.0%
0.0%
 b5- 07 PID Primary Delay Time
Sets the delay time for the PID output filter. Change is normally not required.
No.
Name
Setting Range
Default
b5-07
PID Primary Delay Time
0.00 to 10.00 s
0.00 s
Note: This parameter is effective to avoid the vibration when abrasion is high and rigidity is low. Increasing this
delay time could reduce the response of the drive.
 b5- 08 PID Output Reverse
Reverses the +/- sign of the PID output. This is suitable for reverse acting applications as a
positive PID target decrease the output frequency of the drive.
No.
Name
Setting Range
Default
b5-08
PID Output Reverse
0, 1
0
0 : Normal PID Output
A positive PID input causes an increase in the PID output.
1 : Reverse PID Output
A positive PID input causes an decrease in the PID output.
 b5- 09 PID Output Gain
Sets a gain to multiply by the PID output. The compensation will be more effective when
b5-00=3 or 4.
No.
Name
Setting Range
Default
b5-09
PID Output Gain
0.00 to 25.00
1.00
 b5- 10 PID Output Reverse Selection
Determines whether or not a negative PID output reverses the drive rotating direction. This
parameter is disabled when b5-00 =3 or 4, but the PID output will not be limited (same as
