LIXiSE LXC706 Series User Manual

LXC706 Series Genset Controller
Dongguan Tuancheng Automation Equipment Co.,Ltd.
LXC706 Product User Manual Dongguan Tuancheng Automation Equipment Co.,Ltd.
: +86-769-23836636 : F:+86-769-23166296 : www.lixise.com
Page
11
of
17
P24
Battery Under
Voltage
（
Warning
）
(4.0-30.0)V
8.0V
When battery voltage has fallen below the set value
and remains for 20s, It will initiate a warning alarm
signal. Only warning and not to shutdown the
generator.
（
Return value is 1V
）
.
P25
High
Temperature
(80-140)ºC
98
When the temperature value of the external
temperature sensor exceeds the set value, high
temperature signal is sent. Detecting only after
safety on delay is over. If the set value is 140, high
temperature signal will not be sent (this only concerns
external temperature sensor, not high temperature
signal via configuration. input port).
P26
Low Oil
Pressure
(0-400)kPa
103kPa
When the external pressure sensor value falls below
this set value, low oil pressure signal is sent. Detecting
only after safety on delay is over. If the set value is 0,
low oil pressure signal will not be sent (this only
concerns pressure sensor and does not concern low
oil pressure warning signal via configurable input port).
P27
Low fuel
(0-100)%
10%
When the liquid level of the external liquid level sensor
is smaller than this value and lasts 10 seconds, the
signal level is too low, Only warning and not to
shutdown the generator.
P28
Configurable
output
(0-6)
0
0
：
Not used
1
：
Common alarm
2
：
Energized To Stop output
3
：
Idle control
4
：
Preheat control
5
：
Close Gens
6
：
Reserved
P29
Digital input type
（
0-8
）
0
0
：
not used
1
：
High temperature downtime input
2
：
Low oil pressure shutdown input
3
：
Low fuel warning input
4
：
External shut down input
5
：
High temperature thermal shutdown
6
：
Reserved
7
：
Reserved
8
：
Fuel level sensor
P30
Digital input
activation delay
(0-20)s units
：
0.1s
2.0s
P31
Crank
Disconnect
(0-8)
6
0
：
Freq
1
：
Engine speed
2
：
speed +Electricity generation
3
：
Oil pressure
4
：
Oil pressure + Electricity generation
5
：
Oil pressure + speed
6
：
Oil pressure + speed + Electricity generation
7
：
Charge D+
8
：
Oil pressure + speed + Electricity generation
9
：
Invalid combination
P32
Freq disconnect
(10.0-30.0)Hz
14.0Hz
In the process of cranking, when the gens frequency
exceeds this value, the starter will be separated.
