LXC706 Series Genset Controller
Dongguan Tuancheng Automation Equipment Co.,Ltd.
LXC706 Product User Manual Dongguan Tuancheng Automation Equipment Co.,Ltd.
: +86-769-23836636 : F:+86-769-23166296 : www.lixise.com
NOTE: During the starting delay period, the fuel output disconnect. 3 seconds after entering
the starting delay process, pre-heat and ETS output.After the end of the starting delay period,
ETS output disconnect. Fuel output and pre-heat output disconnect before starting.
Push the button when engine is running, the button beside led will lighten, enter idle
process, idle relay disconnect, idle delay ended, fuel disconnect, ETS solenoid output,
genset stop, ETS solenoid disconnect when genset stop steady.
When engine is waiting state, push button 1 second above, ETS solenoid will output and all
led will be Lighten. Loosen the stop buttons, ETS solenoid output disconnect instantly, and
test lamps function is over.
When engine is waiting state, only emergent stop alarm can be check.
Low Oil Pressure: check after the safe delay, the duration of 5 seconds above, the module
will alarm and stop engine.
High Temperature：check after the safe delay, the duration of 10 seconds above, the
module will alarm and stop engine.
Low Fuel Level: When the fuel level is consistently below the preset value of 10 seconds,
and issuing fuel level is too low signal, this value is only a warning will not stop.
Over speed: check after the preheat delay, the duration of 2 seconds above, the module will
alarm and stop engine.
Under speed: check when engine run at full tilt, the duration of 15 seconds above, the
module will alarm and stop engine.
Over Crank: when engine crank fail over the times of configure, the module will alarm and
stop engine.
Stop Failure: when engine is stop fail, the module will warn.
Battery over voltage: The DC supply has risen above the high volts setting level for the
duration of the high battery volts 20 seconds.
Battery under voltage: The DC supply has low above the under volts setting level for the
duration of the low battery volts 20 seconds.
