11.0 Parts List
Key Part
No. No. Description
1 34675 Housing, Machined
2 32186 Screw, 4-40 x .37
3 32187 Nut,4-40Flush
4 32209 Latch, Machined
5 34710 I/OBoardAssembly
6 31632 Screw, #6 x .38
7 34716 Standoff, Self Adhesive
8 25990 Connector Assembly
9 33566 Solder Lug Terminal
10 34735 Ground Wire Assembly
11 31571 Clamp, Cord (PG-9) (clamp for 4pin cable)
12 34074 Gasket, Foam
13 34088 Cover, Utility Box
14 30588 Label, LMI logo
15 34753 Label, DC4000
16 36525 Front Panel Assembly
17 31617 Cover, Liquitron
™
18 32094 Label, Housing cover LMI
19 32211 Cap, .125 x .38
20 32352 O-Ring,Sponge
21 32395 Screw, Self-Tapping
22 34911 Cover, Fuse
23 32635 Terminal, Grounding
24 34915 Standoff, Hex, M4 x 10 mm
25 30749 Power Cord 115V - DC4000-1
30751 Power Cord 220V US - DC4000-2
30752 PowerCordDIN-DC4000-3
34783 Cord Assembly UK - DC4000-5
30754 Power Cord AUST - DC4000-6
34784 Cord Assembly SWISS - DC4000-7
26 25957-1 Cord Clamp (Pg-9 clamp for female outlet power cord)
27 36810 Dowel
28 34931 Terminal Cover Label
30 35711 Cord,Power,115V,NEMA15-5(femaleoutletpowercord)
31 35712 Fuse, 4A Time Delay
