Lochinvar CP-M Series User Manual

18
Connections
Twin pipe
Concentric
CP-M+
80
CP-M+
100
CP-M+
120
CP-M+
60
CP-M+
80
CP-M+
100
CP-M+
120
AI
Air Inlet
Ø80
Ø100
Ø100
Ø125
Ø125
Ø150
Ø150
FG
Flue Gas
Ø80
Ø100
Ø100
Ø80
Ø80
Ø100
Ø100
F
Flow
R 1 ¼” (male)
C
Condensate
Flexible hose Ø 25/21 x 750 mm
R
Return
R 1 ¼” (male)
G
Gas
R ¾” (male)
Dimension ‘A’
112
112
112
155
112
112
112
Dimension ‘B’
135
135
135
150
135
135
135
FIGURE 3.1 DIMENSIONS CP-M+60, 80, 100 & 120
