LOCK SENSOR (P)
Install on the interior side only. If necessary, trim tab from sensor (P) for doors with 2-3/8"
(60mm) backset. Clean surface of door and doorframe, remove film from adhesive,
attach and secure close to door edge as shown.
2-3/4" (
70mm)
2-3/8" (
60mm)
(P)
15
INSTALLING THE DOORS SENSOR
Step 7
Make sure you have prepared the door sensors for installation, see step 4
