Lockly Vision User Manual

NOTE: When properly installed, the Lockly logo blinks red when door opens and closes.
DOOR FRAME SENSOR (Q)
Manually retract deadbolt and close door. Dry fit sensor (Q) to door frame and check
for alignment. If needed, raise the height of the sensor to be more level with sensor (P)
by adding 1 or 2 of the included adhesive foam pads. Once satisfied both sensors are
as level as possible, remove film from adhesive and install with arrows aligned to each
other with less than a 3/4" gap between each sensor.
16
INSTALLING THE DOORS SENSOR
Step 7
(Q)

Lockly Vision Specifications

General

Type	Smart Lock
Connectivity	Wi-Fi, Bluetooth
Fingerprint Sensor	Yes
Voice Assistant Compatibility	Amazon Alexa, Google Assistant
Material	Zinc Alloy
User Codes	Up to 99
Keypad	Yes
Night Vision	Yes
Two-Way Audio	Yes
Lock Type	Deadbolt
Power Source	4 AA Batteries
Door Thickness	1 3/8" to 2"
Security Features	PIN Genie
Camera Resolution	1080p
