Dispensing5
32
5.1 First Operation
Before loosening the cover screw fasteners 2,
the reservoir must be depressurized
(pressure-free)!
Reservoir 97105 or 97107:
● Set the depressurizing valve 5 to position
(depressurize).
☞
Automatic reservoir only:
The automatic reservoir is depressurized when the power switch on the controller 97102 or 97103 is
switched to the O (OFF) position or the digital display indicates no pressure.
In case of doubt:
● Set the depressurizing valve 5 to position (depressurize).
5.1.1 Inserting the Product Bottle
● Loosen the cover screw fasteners 2 and remove the cover 1.
● Check that the dispensing valve is connected correctly according to the instruction manual.
Never fill the product directly into the reservoir!
The safety devices would become clogged and therefore ineffective!
● Insert a full product bottle in the reservoir
☞
Automatic reservoir only:
● Check that the product bottle inserted in the bottle nesting block is pressed against the level sensor
(see Section 4.3).
● Insert the product hose into the bottle and put
on the cover 1.
● Uniformly tighten the cover screw fasteners 2.
● Set the depressurizing valve 5 to position (pressurize).
● On the controller 97102, switch the reservoir to active with the button .
On the controller 97103, switch the reservoir to active with button or .
