25 -
english
Select antenna cable.
Yellow button: Connect/disconnect antenna cable.
Antenna/cable (analogue):
analogue stations via
cable/antenna
DVB-T: digital terrestrial stations
DVB-C: digital stations via cable
DVB-S (cable 1): digital stations via satellite
DVB-S (cable 2): digital stations via satellite
The selection options for the aerials depend on the
receiver units installed or upgraded at the factory (see
also page 150).
Depending on which antenna(s) was (were) selected, the
appropriate settings are called later during the routine.
OK Proceed.
Select desired languages and alternative
languages for subtitles and audio for DVB
programmes (see page 65).
Set up audio commentary for the visually
impaired (see page 47).
OK Proceed.
Depending on which antennas (DVB-T, DVB-C, DVB-S)
were selected, the appropriate settings appear
below.
Selecting
antennas
Subtitle and
audio
languages
(DVB)
OK
INITIAL INSTALLATION
Connect antenna cable(s)
Antenna cable(s) for: to antenna socket(s):
Antenna/cable (analogue) ANT TV ۪
DVB-T ANT TV ۪
DVB-C ANT TV ۪
DVB-S (cable 1) ANT SAT
DVB-S (cable 2) ANT SAT2
Proceed Connect/disconnect
Back
Network
selection
Settings
Encrypted
stations
Search
method
Supply voltage
Setting options for DVB-T reception:
If you have not selected a DVB-T antenna in the antenna selection: Con-
tinue with setting options for DVB-C reception on page 26.
If several networks are available over DVB-T, you can
decide which network you want to receive your channels
from.
Select network,
OK Proceed.
Select and adapt settings for DVB-T reception.
You can state whether coded stations are to be searched
for in the search/update.
Select yes to save all found
scrambled stations. However, these stations can only
be received in connection with a CA module and the
appropriate Smart Card.
Handling of the CA module is
described on page 67.
If a CA module with a SmartCard is already plugged in for
the station search, all the stations which this module can
descramble are also saved when no is preset.
If you want to run the station search independently of
the channel grid, select frequency search for the search
method.
OK Proceed.
Select supply voltage no / yes.
Use a DVB-T antenna that requires a supply voltage
(active antenna) and which is not already supplied
via a power adapter, then select yes (5V) for the
antenna’s power supply.
How to align your DVB-T antenna is described on
page 35.
OK Proceed.
OK
INITIAL INSTALLATION
Subtitle and audio languages (DVB)
Favoured subtitle language English ...
Alternative subtitle language German
Favoured audio language English
Alternative audio language German
Audio commentary off
Proceed Back
OK
Initial installation
OK
INITIAL INSTALLATION (DVB-T)
Scrambled stations no yes
Search method Channel search
Proceed
OK
yes (5V)
INITIAL INSTALLATION (DVB-T)
Antenna
Supply voltage
no (0V)
Proceed Back
OK
