DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 11
4.1 REQUIREMENTS FOR ASSEMBLY
WARNING
Moderate risk of death or serious injury through electric shocks
Connecting the system incorrectly can lead to death or serious injury through electric
shocks.
• Ensure that the supplied voltage complies with each product's type plate
• Ensure all components are connected to the correct sockets
• Disconnect the Power Hub before removing or connecting any components
• If a Power Hub is used, connect the system to the Mains only after all other com-
ponents (Actuators, User Interfaces, etc.) have been connected to the Power Hub
WARNING
Moderate risk of death or serious injury through electric shocks
Using damaged products may lead to death or serious injury through electric shocks.
• Do not use the User Interface or Power Hub if you see the housing is damaged
CAUTION
Risk of minor or moderate injury through improper handling
Improper handling of the system during assembly may lead to minor or moderate inju-
ry through cutting, pinching, and crushing.
• Read all instructions and safety notices carefully
NOTICE
Ensure proper ESD handling during assembly. Damage that can be attributed to electro-
static discharge will void warranty claims.
NOTICE Before assembly, all parts must be acclimatised to the ambient conditions.
NOTICE Operating the table system when it is not properly connected can damage the product.
• Ensure all Cables are properly connected
• Ensure that all required Actuators are ready to be operated
• Do not operate the DYNAMIC MOTION system until it is properly connected
INFO
Perform a product risk assessment so that you can respond to potential residual haz-
ards. Assembly instructions must be included in your end user Operating Manual
Before assembling the table system, ensure the following requirements are met:
• All Actuators have been mounted properly into the Height-Adjustable Columns
• The Height-Adjustable Columns have been mounted correctly onto the Table Top
• The DYNAMIC MOTION system will be connected at a voltage compliant with the Type Plate
• There is no residual voltage on any parts
4.1.1 TYPES OF TABLE SYSTEM
This Manual contains instructions for 3 types of table system. These are as follows:
Standard Table System (1, 2, 3, or 4 Height Adjustable Columns)
This Table System consists of a single table with 1,2,3, or 4 legs. One Power Hub is used per table.
Benching System
This Table System consists of a group of tables that are controllable individually (in groups). One Power Hub
is used for up to 4 groups.
Table with multiple Power Hubs (Conference Application)
This Table System consists of a single table with up to 8 legs. Multiple Power Hubs are required per table.
This Table System generally supports oversized or very heavy Table Tops.
