DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 29
9.3 DMUI-TOUCH-C-FX
When a DMUI-TOUCH-C-FX Handset is installed alongside the DYNAMIC MOTION system, error messages
are displayed on the digital display panel. These are as follows:
Signal Message Required Actions
The display shows "Hot".
Overheating protection has been
activated.
Wait for the overheated components
to cool.
The display shows "ISP".
The system has recognized a
collision.
Release all Keys and wait for the Drive
Back function to be completed.
The display shows "Con",
then "Err".
The system has recognized a
connection error.
Release all Keys and wait for 5 seconds.
Then, try again.
Disconnect the Power Hub from the
Mains. Then, disconnect System from
the Power Hub. Reconnect the system
again, then operate the DM System as
normal.
The display shows "Err",
then an error number.
An internal error has occurred. Read the table below to nd the correct
response to the error code shown.
Code Message Required Actions
1 Firmware Error Disconnect the Power Hub from the Mains. Then, dis-
connect System from the Power Hub. Reconnect the
system again, then operate the DM System as normal.
2 Motor Over Current Release all Keys and wait for 5 seconds. Then, try again.
3 DC Over Voltage Release all Keys and wait for 5 seconds. Then, try again.
8 Impulse Detection Timeout Perform a Position Reset Procedure (see System Manual)
11 Speed cannot be achieved Release all Keys and wait for 5 seconds. Then, try again.
