SMARTNEO - OPERATING MANUAL // PAGE 12
4.2 DIMENSIONS
Length 188.3 mm | 7.874 "
Width 84.5 mm | 3.328 "
Height 35.0 mm | 1.376 "
Fig. 2: Dimensions SMARTneo-2G (scaled 1:2)
4.2.1 DRILLING TEMPLATE
See overleaf.
84.5 mm
3.328 “
200 mm
7.874 “
188.3 mm
7.411 “
35 mm
1.376 “
