SMARTNEO - OPERATING MANUAL // PAGE 26
9 ACTUATOR SETUP
9.1 PLUG DETECTION
The SMARTneo-2G features Plug Detection. This means that the Control Box recognizes when an Actuator
is connected to the M1 or M2 Plug Port and when an Actuator has been removed or replaced. If an Actuator
has been removed from Plug Port 1 or 2, the SMARTneo-2G will click three times. If a Comfort Hand Control
is installed, the error code E36, E37, or E38 will be shown, depending on which Actuator was removed.
When an Actuator has been removed or replaced, the process you need to follow diers depending on how
the Control Box will continue to be used. Options are as follows:
• If you wish to change the type of LOGICDATA SLIMdrive connected to the SMARTneo-2G (e.g. for
SLIMdrive-660s to SLIMdrive-500), but you do not want to change the number of connected SLIMdrives,
go to Chapter 9.2, SLIMdrive Detection: Changing to a Dierent SLIMdrive Type.
• If you wish to change the number of LOGICDATA SLIMdrives connected to the SMARTneo-2G, go to
Chapter 9.3, Auto Detect: Changing the Number of SLIMdrives.
• If you wish to change the number of Actuators (any type) to the SMARTneo-2G, go to Chapter 9.4,
Changing the Number of Actuators (other).
• If you wish to continue with the same type and number of Actuators, proceed as follows:
1. Disconnect the SMARTneo-2G from the mains and wait for 10-15 seconds
2. Reconnect the missing Actuators to Plug Ports M1/M2 (optional)
3. Reconnect the SMARTneo-2G to the mains
4. Perform a Position Reset Procedure (Chapter 6.7)
▸ You can now use the table system as normal
9.2 SLIMDRIVE DETECTION: CHANGING TO A
DIFFERENT SLIMDRIVE TYPE
NOTICE
Ensure that the Actuator(s) have been safely assembled into the Height-Adjustable
Columns before connecting. Refer to the Actuator's Manual to avoid system damage.
With certain parameterization, the SMARTneo-2G can automatically detect which type of SLIMdrive is con-
nected at the Plug Ports M1/M2 (i.e. SLIMdrive-660s or SLIMdrive-500). Proceed as follows to change the
type of LOGICDATA SLIMdrives connected to the SMARTneo-2G:
1. Perform a Factory Reset (Chapter 8.3)
2. Disconnect the SMARTneo-2G from the mains and wait for 10-15 seconds
3. Disconnect the existing SLIMdrives from the Plug Ports M1/M2 (optional)
4. Connect the new type of SLIMdrive to the Plug Ports M1/M2 (optional)
5. Reconnect the SMARTneo-2G to the mains
▸ The error code E70 will appear on the Hand Control
6. Perform a Position Reset Procedure (Chapter 6.7)
▸ You can now use the table system as normal
