TOUCH FAMILY - OPERATING MANUAL // PAGE 11
5 PRODUCTS
The TOUCH Family of Handsets consists of 3 products:
• TOUCHfx
• TOUCHdown
• TOUCHinlay
Each Handset may have several variants. Variants may be equipped with additional features or dierent
congurations. The exact variant is denoted by the product's order code. Consult the accompanying data
sheet to check ensure that you have received the correct variant.
5.1 KEY PRODUCT FEATURES
5.1.1 TOUCH-FX
1 UP / DOWN Keys
2 Memory Position Keys
3 SAVE Key
4 Display
5 Drilling Holes
6 Strain Relief
*Cable not shown.
Fig. 1: Product features, TOUCHfx
4
5
6
1
2
3
