6.4 ASSEMBLY: TOUCHINLAY
6.4.1 REQUIRED COMPONENTS
The following components are required to assemble the TOUCHinlay:
1 TOUCHinlay Handset
2 Milling cutter (or similar)
6.4.2 PROCESS
1. Use a milling cutter or similar to mill the cut-out. The dimensions for the milled cut-out are
shown in Chapter 5.2.4 (Fig. 7).
2. Push the Handset into the milled cut-out until the top plate is ush with the Table Top. The
rubber ribs will hold the Handset in place.
6.4.3 COMPLETING ASSEMBLY
After the TOUCHinlay is attached to the Table Top, you must connect the Cable to the Control Box. Refer to
the manual for your chosen Control Box for instructions.
