LOGICDATA TOUCH Series - Touchdown; Touchinlay

TOUCH FAMILY - OPERATING MANUAL // PAGE 12
5.1.2 TOUCH-DOWN
1 UP / DOWN Keys
2 Memory Position Keys
3 SAVE Key
4 Display
5 Drilling Holes
6 Supports for Cable Loop
*Cable not shown.
Fig. 2: Product features, TOUCHdown
5.1.3 TOUCH-INLAY
1 UP / DOWN Keys
2 Memory Position Keys
3 SAVE Key
4 Display
5 Rubber Ribs
*Cable not shown.
Fig. 3: Product features, TOUCHinlay
5
6
4
3
1
2
2
1
5
4
3
