TOUCH FAMILY - OPERATING MANUAL // PAGE 16
5.3.2 TOUCH-DOWN
Fig. 9: Drilling Template, TOUCHdown
Side Edge
Front Edge
75.0 mm
2.95 "
34.0 mm
1.34 "
34.0 mm
1.34 "
170.4 mm
6.71 "
106.0 mm
4.17 "
106.0 mm
4.17 "
