LogiCO2 O2 - Alarm Levels

15
7.4 Mk9 O2 Sensor, DIP-switch settings
ID-address 1-4:
ID- address Dip1 Dip2
ID1 OFF OFF
1 2 3 4 5 6 7
ID2 ON OFF
1 2 3 4 5 6 7
ID3 OFF ON
1 2 3 4 5 6 7
ID4 ON ON
1 2 3 4 5 6 7
Alarm levels:
Alarm level Dip3 Dip4 Dip5
A-ALARM: <19.5% >23.0%
B-ALARM: <19.5% >23.0%
OFF OFF OFF
1 2 3 4 5 6 7
A-ALARM: <18.0% >23.0%
B-ALARM: <19.5% >23.0%
ON OFF OFF
1 2 3 4 5 6 7
A-ALARM: <18.0% >23.0%
B-ALARM: <18.0% >23.0%
OFF ON OFF
1 2 3 4 5 6 7
A-ALARM: >23.0%
B-ALARM: >23.0%
ON ON OFF
1 2 3 4 5 6 7
A-ALARM: <19.5%
B-ALARM: <19.5%
OFF OFF ON
1 2
3
4
5
6
7
A-ALARM: <18.0%
B-ALARM: <19.5%
ON OFF ON
1 2
3
4
5
6
7
A-ALARM: <18.0%
B-ALARM: <18.0%
OFF ON ON
1 2 3 4 5 6 7
A-ALARM: PC-software settings
B-ALARM: PC-software settings
ON ON ON
1 2 3 4 5 6 7
Automatic background calibration:
Automatic background calibration Dip6 Dip7
AUTO-CAL activated
Default setting
OFF OFF
1 2 3 4 5 6 7
AUTO-CAL deactivated ON OFF
1 2 3 4 5 6 7
