7.5 Mk9 O2 Sensor, Display information
Display information during start-up:
Start-up software version Start-up test
LogiCO2 O2 Gateway
FW: 1608
ID: 1
Testing system...
Display information during no alarm mode:
Operation O2 concentration Normal view
O2 Level: 20.6%
A-ALARM: <19.5% >23.0%
B-ALARM: <19.5% >23.0%
AUTO-CAL ON
In normal view, the displays shows:
The current O2 concentration in %. Also, the A-ALARM trig
level and the B-ALARM trig level. These levels can be the same
depending on the setting. The A-ALARM activates the audible
(Horn) alarm device and the B-ALARM activates the optical
(Strobe) alarm device.
Display information during alarm mode:
O2 High-Alarm
O2 Level: 19.4%
A-ALARM: <19.5% >23.0%
B-ALARM: <19.5% >23.0%
EVACUATE AREA: Very crit...*
* Information text is only shown during alarm or error situations.
Display information during error/fault mode:
Error/Fault
O2 Level: 20.6%
”Sensor error”
A-ALARM: <19.5% >23.0%
B-ALARM: <19.5% >23.0%
Information text...*
* Information text is only shown during alarm or error situations.
