9.11 Mk9 Central Unit, Display information
Display information during start-up:
Software version Cycle/Start-up
LogiCO2 Central unit
FW: 1420*
*FW = Firmware version
ID CO2 TWA
1 Heating...
Normal display information, one O2 sensor connected:
One O2 sensor is attached
ID CO2 TWA
1 O2: 20.9%
Display information during O2 alarm mode:
O2 Alarm
ID CO2 TWA
1 O2: 16.0%
Gateway Alarm A
Display information during error alarm mode:
Central unit display together with blinking yellow LED and intermittent internal buzzer.
Fault in the O2 sensor measuring device
Error Alarm
ID CO2 TWA
1 Out of range
Information text...*
* Information text is only shown during alarm or error situations.
