GB-6
Preparation Connections Initial Setup Using the Features DVR (Digital Video
Recorder)
Using the Features
via USB port
Hints and Tips, Specification
and Safety Warnings
Front / Top / Side View and Controls
Item Description
1 POWER LED
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will illuminate blue when the timer programming has started in the
standby mode.
2 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 VOL +/-
Adjust the volume.
Select and adjust a setting in the OSD menus.
4 CH +/-
Select a channel.
Select a sub-menu of the OSD menu.
5 MENU Displays the OSD (on screen display) menu.
6 SOURCE
Select among the different input signal sources:
DTV / TV / AV / S-VIDEO / SCART / YPBPR / HDMI / PC
7
/ I
Switch the TV on from standby.
Switch the TV back to standby.
8 POWER ON/OFF Switch on the POWER ON/OFF switch to turn the TV to standby mode.
1 2
8
3 4 6 75
