Lombardini 11 LD Series - Maintenance and Oil Refilling; Engine Maintenance Schedule

16
COMPILER TECO/ATL
REG. CODE
1-5302-296
MODEL N°
50510
DATE OF ISSUE
01.89
REVISION 02
ENDORSED
DATE
17.04.2003
10 50 125 250 500 1000 2500 5000
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
VII
CAPACITIES (LITERS)
Standard fuel tank: LITERS 15
As for filters, tanks and special crankcases please refer to LOMBARDINI instructions.
OPERATION
OVERHAUL
REPLACEMENT
CHECK
CLEANING
(*) Under severe orking conditions, clean daily.
(**) Under extremely dusty conditions, change every 4-5 hours.
(***) See recommended oil type.
(****) Includes checking cylinders, piston rings, guides, springs, grinding valve seats, de-carboning heads and cylinders
as welle as checking injection pump and injectors.
INTERVAL (HOURS)
COMPONENT
AIR CLEANER
FEED PUMP FILTER
HEAD AND CYLINDER FINS (*)
FUEL TANK
INJECTORS
INTERNAL OIL FILTER
AIR CLEANER OIL
LEVEL CRANKCASE OIL
BATTERY FLUID
DELIVERY VALVE TIGHTNESS
FAN BELT TENSION
VALVE AND ROCKER ARM CLEARANCE
INYECTOR SPRAY PATTERN
AIR CLEANER (**) (***)
OIL
CRANKCASE (***)
OIL FILTER CARTRIDGE
FUEL FILTER CARTRIDGE
FAN BELT
PARTIAL (****)
COMPLETE
ENGINE MAINTENANCE 11 LD 535-3 / 11 LD 625-3 / 11 LD 626-3
INSPECTION
MAINTENANCE - RECOMMENDED OIL TYPE - REFILLING
Failure to carry out the operations described in the table may lead to technical damage to the machine
and/or system
